Bubble Ship Aircraft
Prototype for the model served as an aircraft ship from the Oblivion movie, 2013.
The Eiffel Tower in Paris is the most famous monument of the city and all France. Today, the Eiffel Tower in Paris is a 300-meter building (with antennas - 324-meters), weighing more than 10 tons.
Add-on for Calculating Form Cutter
Parametric model of shaped cutter made in T-FLEX CAD. Add-on application for calculations was programmed using Delphi.
Three-dimensional model of the piston head, piston assembly and fixture device for drilling holes on the drilling-milling-boring machine.
Add-on for Calculating Spiral Drills
Parametric model of the drill made in T-FLEX CAD. Add-on application for calculations was programmed using Delphi.
3D-model is implemented on a good professional level using not only basic modeling operations such as extrusions and rotations but also quite complex blends.
Gearwheel with Vaulted Tooth Profile
Parametric modeling of gears made in T-FLEX CAD. Add-on application for calculations was programmed using Delphi. The presented model uses pre-pole engagement of gear teeth.
Rotor Unit Assembly
3D models of components and assembly unit used for the main rotor assembly modeling. Advanced modeling operations were used when modeling parts. Assemblies and subassembly use mates.
Kinematic Control System for Glider
The project goal is to show cockpit controls operation by means of T-FLEX CAD mates and transformation options. 3D model of glider with cockpit controls was designed within this project. Using this model, wing mechanization has been shown.
Now this project is used within educational process for the course “Construction and design of aircraft”. Students study glider cockpit , control elements, transversal and longitudinal stability of glider using virtual 3D model.
3D Models of Forged Parts
3D models of garden house and chandelier – products of artistic forging - are presented at competition.
