Wave Line
The wave line style can now be assigned, besides the straight lines, to arcs, ellipses, splines and polylines. The waves parameters no longer depend on the graphic line length and can be specified separately for each line. The wave length can either be specified by value, or defined as the number of waves on the line. The wave height is specified as a percentage of the wave length.
01.png)
Waves are supported when defining hatch contours.
User-Defined Line Types
The user can now create custom line types. These can be defined by common T-FLEX CAD drafts created according to certain simple conventions. The definition may contain the drafting of the periodical pattern, the start, the end and the middle of the segment. The periodicity conditions must be defined. The characteristic points of the line type are defined by the special named nodes.
The user-defined line types are also supported when defining hatch contours.
When the drafting files of the user-defined line types are edited, deleted or created, they are automatically appended at the end of the line type list. When a user-defined line type is used in a document, its parameters do not reference the file of origin. Therefore, the line type will still be supported on another computer where the type-defining file is not present.
02.png)
|
