Customer Cases

Twenty-Eight-Foot Wooden Steam Boat of the Russian Imperial Navy with a White System Boiler, Model 1870-1875 Twenty-Eight-Foot Wooden Steam Boat of the Russian Imperial Navy with a White System Boiler, Model 1870-1875

The 28-foot wooden steam boat of the Russian Imperial Navy with a White system boiler, model 1870-1875.

Project is made in the T-FLEX CAD 15

Precise Tooth Profile Precise Tooth Profile

The author was able to create an accurate tooth profile.

The model is made in T-FLEX CAD 16.

Log Semi-trailer Log Semi-trailer

The model is create in the form of a multilevel assembly, created using the bottom-up method

Wooden Clock Wooden Clock

The main purpose of the project was to study the capabilities of T-FLEX CAD 16. The project was done at home in free time from the main work. A free Student Edition was used for modeling.

Refrigeration Evaporator Refrigeration Evaporator

This device was made to replace a failed device at one of the enterprises.

Screw Press for Vegetable Oil Extraction Screw Press for Vegetable Oil Extraction

A screw press for pressing vegetable oil is an import-substituting project. The project is fully developed, contains drawings of parts, assemblies and bill of materials.

Block of Air Coolers Block of Air Coolers

The assembly was modeled using the bottom-up method. In the process of creating the assembly, the parametric capabilities of T-FLEX CAD were actively used.

The assembly of the apparatus consists of more than 60,000 bodies.

Multifunctional Cybernetic Prosthesis Multifunctional Cybernetic Prosthesis

The multifunctional cybernetic transfemoral prosthesis is a mechatronic device with a control system created on the basis of an intellectual-synergetic concept, designed for social rehabilitation of disabled people with transfemoral amputation of activity groups M1-M4

Trike with D6 Engine Trike with D6 Engine

The project used several nested assemblies for the convenience of subsequent assembly. A large number of standard fasteners (screws, bolts, washers, nuts), bearings, cups were used.
The engine is 3D printed. The author's project was made in the T-FLEX CAD 16.

Rotator Rotator

The Rotator project stands out for its complexity.
Contains CAD, CAM, CAE, drawings, product structure and is made in the T-FLEX CAD 16.
