Contest Projects



Racing Car Racing Car

The aim of this project is to create a Lego-style sports car model and use this model in the development of a racing simulator game
The project was created in the T-FLEX CAD 16 Student Edition.

3D Printer 3D Printer

The author designed and assembled a 3D printer in the T-FLEX CAD 16 Student Edition.

Guitar Guitar

The project is a model of blanks that will be made on a CNC machine (body and neck of an electric guitar)
This model is made in T-FLEX CAD 16 Student Edition.

Turbojet Engine Turbojet Engine

A model of a turbojet engine made in T-FLEX CAD 16 Student Edition.

SRAV-01 Scout Robot All-terrain Vehicle SRAV-01 Scout Robot All-terrain Vehicle

A feature of creating the presented model is the organization of the design of the model according to the "top-down" principle.
The project was created in the T-FLEX CAD 14 Student Edition.

Spider-Tank Spider-Tank

The 3D model of the assembly is made on mates: the tower rotates, it is possible to open the cockpit, change the angle of the gun, change the position of the paws in 3 planes with the simulation of robotic hydraulic cylinders.
The project was created in the T-FLEX CAD 14 Student Edition.

Tank TK-1000 Tank TK-1000

Model of a futuristic tank made in T-FLEX CAD Student Edition 14.

Bubble Ship Aircraft Bubble Ship Aircraft

Prototype for the model served as an aircraft ship from the Oblivion movie, 2013.

Eiffel Tower Eiffel Tower

The Eiffel Tower in Paris is the most famous monument of the city and all France. Today, the Eiffel Tower in Paris is a 300-meter building (with antennas - 324-meters), weighing more than 10 tons.

Add-on for Calculating Form Cutter Add-on for Calculating Form Cutter

Parametric model of shaped cutter made in T-FLEX CAD.  Add-on application for calculations was programmed using Delphi.
